IPDU Per Inlet Monitored Light
Metered Intelligent Power Distribution with remote internet access for information per inlet. (No SNMP Controller)
- Rack Mountable Intelligent Power Distribution Unit (IPDU): Our IPDU offers versatile rack mounting with horizontal, vertical, and toolless options.
- Advanced IP Access and Technology: Equipped with robust IP access features, including DHCP, IPv4 and IPv6 support, DNS, HTTP/HTTPS, SSHv.2, SNMP v1/v2c/v3, SNMP TRAPS/SETS/GETS, SMTP, Modbus, TCP, RADIUS, Syslog, TLS 1.3, SNTP, ARP, ICMP, ICMPv6, UDP, and NDP.
- Environmental Sensors: The IPDU features an all-in-one temperature and humidity sensor. It supports 2 digital inputs for various environmental factors like door open detection, water leakage, smoke, air flow, and vibration. The plug-and-play bus allows the connection of up to 8 Environmental Monitoring Devices (EMD) to a single IPDU.
- IEX (C13/C19) Combo Socket: Our IPDU is equipped with an IEX combo socket, supporting a wide range of C14 and C20 plugs, making it the most versatile choice for your power distribution needs.
- High-Temperature Grade Components: Engineered with high-temperature grade components, our IPDU ensures safe and reliable operation in environments with temperatures up to 60ºC (140ºF).
Item no.
PIML-V-36-24IEX
MAX. CURRENT (A)
16
RATED VOLTAGE / PHASE
230V / 1~
OUTLETS
24x IEX
INPUT PLUG
CEE 3-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1042
REMARKS
H05VV-F3G1,5mm2
Item no.
PIML-V-72-24IEX
MAX. CURRENT (A)
32
RATED VOLTAGE / PHASE
230V / 1~
OUTLETS
24x IEX
INPUT PLUG
CEE 3-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1262
REMARKS
H07RN-F3G4mm2
Item no.
PIML-V-11-24IEX
MAX. CURRENT (A)
16
RATED VOLTAGE / PHASE
400V / 3~
OUTLETS
24x IEX
INPUT PLUG
CEE 5-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1362
REMARKS
H07RN-F5G2,5mm²
Item no.
PIML-V-22-24IEX
MAX. CURRENT (A)
32
RATED VOLTAGE / PHASE
400V / 3~
OUTLETS
24x IEX
INPUT PLUG
CEE 5-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1662
REMARKS
H07RN-F5G4mm²
Item no.
PIML-V-36-36IEX
MAX. CURRENT (A)
16
RATED VOLTAGE / PHASE
230V / 1~
OUTLETS
36x IEX
INPUT PLUG
CEE 3-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1412
REMARKS
H05VV-F3G1,5mm2
Item no.
PIML-V-72-36IEX
MAX. CURRENT (A)
32
RATED VOLTAGE / PHASE
230V / 1~
OUTLETS
36x IEX
INPUT PLUG
CEE 3-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1612
REMARKS
H07RN-F3G4mm2
Item no.
PIML-V-11-36IEX
MAX. CURRENT (A)
16
RATED VOLTAGE / PHASE
400V / 3~
OUTLETS
36x IEX
INPUT PLUG
CEE 5-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1512
REMARKS
H07RN-F5G2,5mm²
Item no.
PIML-V-22-36IEX
MAX. CURRENT (A)
32
RATED VOLTAGE / PHASE
400V / 3~
OUTLETS
36x IEX
INPUT PLUG
CEE 5-pins
CABLE LENGTH (m)
3 meter
LENGTH HOUSING (mm)
1812
REMARKS
H07RN-F5G4mm²
| Article | Description | MAX. CURRENT (A) | RATED VOLTAGE / PHASE | OUTLETS | INPUT PLUG | CABLE LENGTH (m) | LENGTH HOUSING (mm) | REMARKS | Order | |
| PIML-V-36-24IEX | IPDU PIML 1x16A, 24xIEX, H05VV-F3G1.5mm² 3M CEE plug | 16 | 230V / 1~ | 24x IEX | CEE 3-pins | 3 meter | 1042 | H05VV-F3G1,5mm2 | ||
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 24x IEX INPUT PLUG CEE 3-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1042 REMARKS H05VV-F3G1,5mm2 | ||||||||||
| PIML-V-72-24IEX | IPDU PIML 1x32A, 24xIEX, H07RN-F3G4mm² 3M CEE plug | 32 | 230V / 1~ | 24x IEX | CEE 3-pins | 3 meter | 1262 | H07RN-F3G4mm2 | ||
MAX. CURRENT (A) 32 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 24x IEX INPUT PLUG CEE 3-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1262 REMARKS H07RN-F3G4mm2 | ||||||||||
| PIML-V-11-24IEX | IPDU PIML 3x16A, 24xIEX, H07RN-F5G2,5mm² 3M CEE plug | 16 | 400V / 3~ | 24x IEX | CEE 5-pins | 3 meter | 1362 | H07RN-F5G2,5mm² | ||
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 400V / 3~ OUTLETS 24x IEX INPUT PLUG CEE 5-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1362 REMARKS H07RN-F5G2,5mm² | ||||||||||
| PIML-V-22-24IEX | IPDU PIML 3x32A, 24xIEX, H07RN-F5G4mm² 3M CEE plug | 32 | 400V / 3~ | 24x IEX | CEE 5-pins | 3 meter | 1662 | H07RN-F5G4mm² | ||
MAX. CURRENT (A) 32 RATED VOLTAGE / PHASE 400V / 3~ OUTLETS 24x IEX INPUT PLUG CEE 5-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1662 REMARKS H07RN-F5G4mm² | ||||||||||
| PIML-V-36-36IEX | IPDU PIML 1x16A, 36xIEX, H05VV-F3G1.5mm² 3M CEE plug | 16 | 230V / 1~ | 36x IEX | CEE 3-pins | 3 meter | 1412 | H05VV-F3G1,5mm2 | ||
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 36x IEX INPUT PLUG CEE 3-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1412 REMARKS H05VV-F3G1,5mm2 | ||||||||||
| PIML-V-72-36IEX | IPDU PIML 1x32A, 36xIEX, H07RN-F3G4mm² 3M CEE plug | 32 | 230V / 1~ | 36x IEX | CEE 3-pins | 3 meter | 1612 | H07RN-F3G4mm2 | ||
MAX. CURRENT (A) 32 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 36x IEX INPUT PLUG CEE 3-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1612 REMARKS H07RN-F3G4mm2 | ||||||||||
| PIML-V-11-36IEX | IPDU PIML 3x16A, 36xIEX, H07RN-F5G2,5mm² 3M CEE plug | 16 | 400V / 3~ | 36x IEX | CEE 5-pins | 3 meter | 1512 | H07RN-F5G2,5mm² | ||
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 400V / 3~ OUTLETS 36x IEX INPUT PLUG CEE 5-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1512 REMARKS H07RN-F5G2,5mm² | ||||||||||
| PIML-V-22-36IEX | IPDU PIML 3x32A, 36xIEX, H07RN-F5G4mm² 3M CEE plug | 32 | 400V / 3~ | 36x IEX | CEE 5-pins | 3 meter | 1812 | H07RN-F5G4mm² | ||
MAX. CURRENT (A) 32 RATED VOLTAGE / PHASE 400V / 3~ OUTLETS 36x IEX INPUT PLUG CEE 5-pins CABLE LENGTH (m) 3 meter LENGTH HOUSING (mm) 1812 REMARKS H07RN-F5G4mm² | ||||||||||
